Outdoor LED display-Outdoor Advertising Led Display

製品の詳細

起源の場所: 深セン

ブランド名: HSCXLED

証明: KC CE CE-LVD CE-EMC ROHS FCC CCC ISO9001

モデル番号: P3.9/P4.8/P6.25/P5.7/P6.67/P8/P10

支払いと送料の条件

最小注文数量: 1セット

パッケージの詳細: 戦闘ケース/木製ケース/ハニークームボックス

受渡し時間: 15-20work日

供給の能力: 1000セット

お問い合わせ
製品の詳細
ハイライト:

Outdoor Advertising LED Display Screen

,

Outdoor Waterproof Led Screen

,

Outdoor HD LED Display for Advertising

製品名:
LEDビデオディスプレイパネル
タイプ:
導かれた
応用:
アウトドア
色:
フルカラーLEDスクリーン
ピクセル:
P3.9/P4.8/P5.7/P6.2/P6.67/P8/P10
使用法:
屋外での広告ディスプレイ
キーワード:
屋外アルミニウム LED スクリーン
輝度:
5000-8000cd/m²
防水:
IP65-IP68
リフレッシュレート:
3840Hz、7680Hz
電源:
AC100~240V
キャビネットのサイズ:
960*960mm
材料:
プロフィール アルミニウム
仕様:
ビデオ壁は、スクリーンを導いた
表示機能:
ビデオ/テキスト/画像/時間/3Dテキスト/オフィス/SWF
製品名:
LEDビデオディスプレイパネル
タイプ:
導かれた
応用:
アウトドア
色:
フルカラーLEDスクリーン
ピクセル:
P3.9/P4.8/P5.7/P6.2/P6.67/P8/P10
使用法:
屋外での広告ディスプレイ
キーワード:
屋外アルミニウム LED スクリーン
輝度:
5000-8000cd/m²
防水:
IP65-IP68
リフレッシュレート:
3840Hz、7680Hz
電源:
AC100~240V
キャビネットのサイズ:
960*960mm
材料:
プロフィール アルミニウム
仕様:
ビデオ壁は、スクリーンを導いた
表示機能:
ビデオ/テキスト/画像/時間/3Dテキスト/オフィス/SWF
製品説明

Outdoor aluminum LED screen LED Display Billboard Sign Board



LED display for Outdoor Advertising/Full Color Advertising LED Display Screen



Full Color LED Display Screen Outdoor / HD Video Wall Advertising Screen



Outdoor LED Display Advertising Screen /Waterproof LED Screen

Outdoor LED display-Outdoor Advertising Led Display 0


Outdoor aluminum LED display Paramenters:


HSCXLED-Outdoor LED display --Outdoor aluminum profile enclosure LED screen
Model P3.91 P4.81 P6.25 P5.71 P6.67 P8 P10
Pixel pitch 3.91mm 4.81mm 6.25mm 5.71mm 6.67mm 8mm 10mm
LED configuration SMD1921 SMD1921 SMD1921 SMD 2727 SMD 2727 SMD 2727 SMD 3535
Module size 500*250mm 480*320mm
Scan mode 1/16 scan 1/13 scan 1/5 scan 1/7scan 1/6 scan 1/5 scan 1/2 scan
Pixel matrix per Module 128*64 dots 104*52 dots 80*40 dots 84*56 dots 72*48 dots 60*40 dots 48*32 dots
Pixel density(dots/sqm) 65,536 43,264 25,600 30,670 22,477 15,625 10,000
Screen size 1000*1000mm 960*960mm
Refresh rate ≥3840HZ
Box material profile aluminum
Brightness 4500nit 4500nit 6000nit 5500-10000nit
Ingress Protection IP67
Weight ≤28kg/m²
Viewing Angle H 160° / V 160°
AC Input Voltage AC 110V/220V±10%,50Hz/60Hz
Gray Level 14bit
Working Temperature -20 -50(℃)
Maximum power  600W/m²
average power  200W/m²
Operating Humidity 10%~95% RH
Video Format Support RM,FLV,AVI,MP4 and other mainstream video formats
Picture Format Support JPG,PNG,and other image formats
Life Time ≥ 100000(Hours)

Outdoor LED display-Outdoor Advertising Led Display 1

Outdoor aluminum LED display Features:




High-Brightness,Energy-Saving Aluminum LED Display



HSCXLED-Outdoor aluminum LED screen support multiple module model selections,Use standard universal 500*250mm size display module.Aluminum profile box, light and thin,The product has high brightness, high refresh rate,Modular design, low installation and maintenance costs, fast speed, supports front and rear maintenance and high protection level.


Front & RearMaintenance


No need for a rear access channel,offering a sleek appearance and cost-effective structure.


High Protective Performance


Outdoor display screen has high requirements on protection level. HSCXLED-Outdoor aluminum LED screen front and rear protecting level is IP68/IP67. With the highest standard of waterproofing. All-day work, fully capable of any harsh environment, features with anti-corrosion, moisture-proof etc.


Strong Flame Resistance


outdoor LED display screens , high temperature durability, fast heat dissipation with Noise-free, it is able to used at high temperature for a long time without deformation.


All-Weather Durability


Our IP65 waterproof LED modules offer exceptional protection against extreme weather ensuring stable performance and longevity. The fanless power supply with waterproof seals further guarantees durability and reliable operation.


High Refresh Rate


The screen display is smooth without lag,with a high refresh rate of up to3840-7680Hz.fast response speed,and no dragging,lagging,or flickering.The screen display is smooth and stable.High guality modules,Modular design for easy splicing true color high stability and long life.


Smart Control System


For cloud control,Wi-Fi control,USB Disk,4G/5G,our smart control system are allowed to make it.

Outdoor LED display-Outdoor Advertising Led Display 2

Outdoor LED display-Outdoor Advertising Led Display 3

Outdoor Advertising led display Advantages:



Cost-Effective HD:



Outdoor led display Balances high resolution and lower investment vs. smaller-pitch screens; ideal for large-area outdoor HD advertising.



All-Weather Adaptability:



Outdoor LED advertising LED display screen adopts outdoor sealed waterproof box or integrated die cast aluminum box, with high protection level, meeting the needs of outdoor environment use.Waterproof, dustproof, and temperature-resistant for year-round outdoor operation with minimal downtime.



Low TCO:



HSCXLED - Outdoor LED advertising screens are made of lightweight and convenient materials, and support front and rear maintenance modes.Energy efficiency, long life, and easy maintenance reduce power, labor, and replacement costs over the lifecycle.



Strong Visual Impact:



Our outdoor display screen uses high-quality LED chips, IC, and PCB for outdoor advertising,Dynamic video, rich colors, and large-format display capture attention better than static posters; programmable content supports targeted, real-time campaigns.



Scalable & Customizable:



As a LED display supplier with 10 years of experience, HSCXLED supports customization for both outdoor advertising LED displays and indoor high-definition LED displays. We offer ODM/OEM services.

HSCXLED- The led screens Spliceable to any size; supports flat led screen, curved led display screen, or special shapes led to fit architectural and branding needs.nd branding needs.




Outdoor Advertising Led Display Applications:



Advertising publish,retail store,shopping mall,display of dishes,welcome display,self-service business,exhibition hall,Restaurant & Hotel Supplies,education,medical treatment...


Outdoor LED Display/Outdoor aluminum  LED screen



Outdoor advertising led display



Outdoor Waterproof Aluminum Profile LED Display



Outdoor aluminum  LED display/Exterior Digital LED Advertising Screen
